Specifications

Application: liquid

Range: (0.1~10)meters

Antenna  Size: 21mm lens antenna

Process Fitting: Thread G1½ A″ /  Flange ≥DN80

Process Temperature: (-40~100)°C

Process Pressure: (-0.1~1.6)MPa

Protection Rating: IP67

Accuracy: ±5mm

Launch angle: 14°

Supply: Two-wire / DC 24V

               Four-wire /AC 220V

               Six-wire / DC 12V...24V

Output:   4~20mA /HART(2-wire/4-wire/6-wire)

               Modbus-RS485
